Yaman Steel has made a name for itself as a trusted manufacturer and supplier of Monel 400 Flanges in Mumbai, India. They pride themselves on delivering products that adhere to strict international quality standards. With a keen emphasis on precision manufacturing and maintaining material integrity, Yaman Steel provides Monel 400 Flanges that are perfect for even the most demanding industrial settings. Thanks to their advanced production techniques and rigorous inspection processes, they guarantee consistent quality, precise dimensions, and dependable performance. Their Monel 400 Flanges are highly regarded for critical piping systems, known for their durability, resistance to corrosion, and long-lasting operational life, making Yaman Steel a reliable partner for both local and international clients.
These flanges are crafted from carbon steel alloys, which mainly consist of iron and carbon, along with carefully controlled amounts of manganese, silicon, and other elements to boost strength and hardness. The carbon content plays a key role in providing excellent mechanical properties, including high tensile strength, good yield strength, and impressive load-bearing capacity. Plus, they offer great machinability, impact resistance, and structural stability. In high-pressure environments, these flanges perform exceptionally well and promise a long service life when used under the right conditions.
| Specification | ASTM B564 / ASME SB564 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating ANSI | Class 150 LBS, 300 LBS, 400 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203; UNI2276 |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Yaman Steel is the largest manufacturer and exporter of Pipe, Fittings, Flanges in Mumbai, India, known for delivering high-quality products to clients across the globe. With state-of-the-art manufacturing facilities and a team of skilled professionals, the company ensures flanges with superior strength, durability, and reliability that meet international standards. Yaman Steel offers a wide range of sizes, grades, and specifications, catering to industries such as oil and gas, petrochemical, power, and water treatment. For inquiries and orders, contact us at sales@pipefittingsflanges.com.
These flanges find extensive use in industries where corrosion resistance and high strength are crucial. Common applications include marine engineering, seawater piping systems, offshore oil and gas platforms, chemical processing plants, and heat exchangers. They are also utilized in power generation, petroleum refining, and desalination facilities. Thanks to their outstanding performance in both acidic and alkaline environments, Monel 400 Flanges are perfect for managing corrosive fluids and high-pressure systems, ensuring reliable operation, minimizing maintenance needs, and extending service life.
