Yaman Steel is a trusted manufacturer and supplier located in Mumbai, India, specializing in high-quality Carbon Steel BS 3601 Pipes designed for both pressure and structural applications. These pipes are crafted in line with BS 3601 standards, which guarantees consistent quality, strength, and precise dimensions. Thanks to our state-of-the-art manufacturing facilities and rigorous quality control measures, Yaman Steel delivers BS 3601 Pipes that are perfectly suited for the demands of tough industrial settings. Our dedication to precision, durability, and on-time delivery has made us a go-to supplier for carbon steel piping solutions, both locally and internationally.
Our Carbon Steel BS 3601 Pipes are made from carbon-manganese steel, featuring a carefully controlled chemical composition that includes carbon, manganese, phosphorus, and sulfur. This blend ensures excellent strength, toughness, and weldability. On the mechanical side, these pipes provide the right yield strength, tensile strength, and elongation properties needed for pressure and structural service. They are engineered to handle internal pressure, mechanical loads, and fabrication processes without sacrificing performance or safety.
| Dimensions | ASTM, ASME and API |
| Thickness | 50mm to 7.00mm, custom OD and thickness available on request |
| End | Plain End, Beveled End, Treaded |
| Length | Single Random, Double Random & Required Length, Custom Size – according to customer’s requirement |
| Schedules | SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules |
| Types | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter | 19.05mm to 127mm |
| Wall Thickness | 0.8mm to 6.0mm |
| Length | 6mtr/ 12mtr or Cut to Length |
| Capacity | 7000 Mt/Month |
Grade | Mfg. Process | Chemical Composition(%) | ||||||||
C | Si | Mn | P | S | Ni | Cr | Mo | Others | ||
BW320 | B | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW320 | E | 0.16Max | – | 0.30~0.70 | 0.040Max | 0.040Max | – | – | – | – |
ERW360 | E | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.050Max | – | – | – | – |
ERW430 | E | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | – |
S360 | S | 0.17Max | 0.35Max | 0.40~0.80 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
S430 | S | 0.21Max | 0.35Max | 0.40~1.20 | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
SAW430 | A | 0.25Max | 0.50Max | 1.20Max | 0.040Max | 0.040Max | – | – | – | t 16mmMax 16mm<t 40mmMAX 40mm<t 65mmMax |
|
Grade
|
Tensile Test MPa or N/mm2 |
Remaks (Similar to JIS) |
Possibility Temperature |
|
|
Min Yield point |
Tensile Strength |
|||
|
BW320 |
195 |
320~460 |
– |
|
|
ERW320 |
195 |
320~460 |
– |
|
|
ERW360 |
235 |
360~500 |
(STPG370) |
|
|
ERW430 |
195 |
430~570 |
(STPG410) |
|
|
S360 |
235
225
215 |
360~550 |
(STPG310) |
|
|
S430 |
275
265
255 |
430~570 |
(STPG410) |
|
|
SAW430 |
275
265
255 |
430~570 |
(STPY400) |
|
Yaman Steel is the largest manufacturer and exporter of Pipe, Fittings, Flanges in Mumbai, India, known for delivering high-quality products to clients across the globe. With state-of-the-art manufacturing facilities and a team of skilled professionals, the company ensures flanges with superior strength, durability, and reliability that meet international standards. Yaman Steel offers a wide range of sizes, grades, and specifications, catering to industries such as oil and gas, petrochemical, power, and water treatment. For inquiries and orders, contact us at sales@pipefittingsflanges.com.
You’ll find Carbon Steel BS 3601 Pipes being used in a variety of applications, including pressure vessels, boilers, heat exchangers, and pipeline systems. They are particularly common in power generation plants, oil and gas sectors, refineries, and petrochemical facilities. Additionally, these pipes are ideal for structural applications, mechanical components, and general engineering tasks. Thanks to their strength, reliability, and versatility, BS 3601 Pipes are the preferred choice for projects that require safe operation and long-lasting performance.
